UV-CTP SII is dedicates to high Level customers who are using UV-CTP plates it has high sensitivity, more run lengths, and can working with the UV ink printing.
Technical specifications
| Type | Positive working CTcP-UV |
| Substrate | Electromechanical grained and anodized aluminium |
| Coating Color | Blue |
| Plate Gauges | 0,15 / 0,15 P / 0,20 / 0,30 / 0,40 mm |
| Application | Sheet-fed and Coldset / Heatset web presses |
| Laser Characteristics | UV – Ultraviolet |
| Spectral Sensitivity | 400-410 nm |
| Energy Required | 50-60 mJ/cm2 |
| Screen Reproduction | 2 – 98% @ 200 l.p.i. |
| Resolution | Up to 3200 d.p.i. and FM screen 20 µm |
| Safelight | White 1 h / Yellow 6 h |
| Development | Use Strong developers and replenishers |
| Processing Conditions | Temperature: 22 ±1℃ Dev. Time: 20-30 seconds |
| Finishing Gum | Use Strong Gum for standard process |
| Run Length | 50.000-100.000 impressions – Unbaked |
| Shelf Life | 24 months |
| Storage Conditions | Temperature: Up to 30℃ Relative Humidity: Up to 70% |
